| Main Feature | ||
| Antenna | Built-in intelligent antenna Antenna Gain: 2.4 GHz radio: 9 dBi 5 GHz radio: 9 dBi |
|
| Buttons | 1 x Reset button | |
| Frequency | Dual-radio and up to four spatial streams: 2.4 GHz/5 GHz, two spatial streams, 2x2 MU-MIMO 5 GHz, two spatial streams, 2x2 MU-MIMO |
|
| Wireless | 802.11b/g/n/ax, Wi-Fi 6 | |
| Interface | 1 x 10/100/1000Base-T Ethernet port, supporting PoE input 1 x GE SFP port 1 x RJ45 console port (serial console port) 1 x multi-color system status LED 3 x single-color RSSI LEDs |
|
| Data Rate | Combined peak date rate for 2.4 GHz and 5 GHz radios: 1.775 Gbps Combined peak date rate for 5 GHz and 5 GHz radios: 2.4 Gbps |
|
| Power | Power Supply: 8 V DC/0.35 A power input over DC connector: The DC connector accepts 2.0 mm/6.3 mm center-positive circular plug. A DC power adapter needs to be purchased independently. PoE input over ETH/PoE: The power source equipment (PSE) complies with IEEE 802.3af/at standard (PoE/PoE+). Power Consumption: 12.95 W |
|
| Environment | Operating temperature: –40°C to +65°C (–40°F to +149°F) Storage temperature: –40°C to +85°C (–40°F to +185°F) Operating humidity: 0% to 100% RH (non-condensing) Storage humidity: 0% to 100% RH (non-condensing) |
|
| Physical Specifications | ||
| Dimensions | 251 mm x 168 mm x 64 mm (9.88 in x 6.61 in x 2.52 in) | |
| Weight | Main unit: 1.5 kg (3.31 lbs) Mounting bracket: 0.2 kg (0.44 lbs) |
|
| Color | White | |
| Warranty Information | ||
| Warranty | 3 Year Warranty | |
The Ruijie RG-AP680(CD) 2400Mbps Wi-Fi 6 Wireless Outdoor Access Point The highest protection against solid ingress and water ingress, resisting water, dust, and sand. Built-in high-grade surge protection component that can withstand 9KV surge voltage, ensuring stable operation in thunderstorms. withstanding extreme variations in temperature from -40°C to +65°C, ideal for outdoor environments in different regions. OFDMA and MU-MIMO technologies are introduced for stable multi-STA connections. OFDMA supports concurrent data transfer to multiple STAs at a latency as low as 20 ms. WPA3 is used to dramatically increase wireless security. 1024QAM modulation delivers a 25% increase in data rate compared with IEEE 802.11ac. The Ruijie RG-AP680(CD) 2400Mbps Wi-Fi 6 Wireless Outdoor Access Point has a 3-year warranty.
